StarTech.com USB Galvanic Isolator 6KV, Electrical Noise Isolator, IP40, DIN Rail, Isolated Power Filter, USB 2.0/1.1, TAA

Safeguard sensitive computing equipment and USB devices from harmful voltage spikes, ground loops, and electrical interference with this USB Galvanic Isolator. Protect mission-critical devices from potential electrical hazards with Level 4 ESD protection with a 6,000V rating for up to 1. The voltage isolator provides galvanic isolation in harsh environments, with an operating temperature range of -22 to 167°F (-30 to 75°C). Its in-line design enables straightforward plug-and-play installation with no additional setup or software configuration. Connect the isolator between the USB device and the host computer for immediate protection. Compatible with USB 2.0 (12Mbps) and USB 1.1 devices, it supports up to 5V 250mA and can provide up to 5V 500mA using an external power adapter (not included). The compact footprint (3.5x2.2x0.9 inches / 89x55x24 mm) of the TAA-compliant USB isolator makes it perfect for space-constrained installations. It can be mounted on a DIN rail or used as a stand-alone device. The small housing features IP40-rated protection and meets certifications such as CE/LVD (2014/35/EU) and IEC/EN 62368-1.

U1-USB-ISOLATOR

Brand	‎StarTech.com
Manufacturer	‎StarTech.com
Model	‎U1-USB-ISOLATOR
Part Number	‎U1-USB-ISOLATOR
Compatible Devices	‎Laptop, Desktop
Number of Items	‎1
Batteries included	‎No
Batteries Required	‎No
Number of Ports	‎2
Item model number	‎U1-USB-ISOLATOR
Product Dimensions	‎5.59 x 8.89 x 2.29 cm; 72.57 g
ASIN	‎B0DLH7WBLD
Date First Available	Oct. 30 2024
Best Sellers Rank	#110,443 in Electronics (See Top 100 in Electronics) #194 in DA Converters
Compatible devices	Laptop, Desktop
Specific uses for product	PC
Connector type	USB Type B, USB Type A
Colour	Black
Item dimensions L x W x H	5.6 x 8.9 x 2.3 Centimetres
