StarTech.com 4-Slot PCIe Expansion Chassis w/PCIe x2 Host Card, PCIe 2.0-10Gbps, External PCIe Slots for Desktops/Servers, PCI Express Expansion Box/Adapter, 4 PCIe x1 Slots (4PCIE-PCIE-Enclosure) 4 Slot PCIe

The robust expansion chassis supports up to 4 PCIe x1 add-on cards and features up to 10Gbps of total bandwidth. The expansion chassis connects to the host using a proprietary USB-C PCIe x2 adapter card and a locking USB Type-C cable. External PCIe Expansion Box The chassis communicates with the desktop computer or server using a host card (PCIe 2.0 x2) in combination with the 5.9ft (1.8m) USB Type-C (USB-C) cable with screw-locks. The included low-profile bracket widens the compatibility as you can install the host card in small form factor (SFF) systems. Features support for PCI-E Advanced Error Reporting (AER) and EndPoint Cyclic Redundancy Check (ECRC). Both of these PCIe features to aid in establishing and maintaining PCIe connections between devices. The PCI express expansion box does not require drivers to be installed. It's operating system independent; meaning it can be used in Windows, Linux, or macOS. Note: the expansion cards installed in the chassis may require drivers. Robust Construction The expansion chassis is built with SECC galvanized steel, enabling it to operate in harsh environments. It features an operating temperature range of 32° to 140°F (0° to 60°C). The vented design of the chassis allows for passive cooling and quiet operation. Secure the enclosure to the desired location using the mounting brackets and included hardware. Power Options Power the expansion chassis using the included 12V 3A power adapter or the terminal block port that supports 12 to 24V and 3A. Applications There are multiple application scenarios: Upgrade or swap cards with ease. Test hardware between multiple computers, operating systems, or with different devices/peripherals. Maximize the I/O capabilities of the host system by installing Ethernet or fiber, USB, serial, or parallel PCIe cards. Avoid costly computer/server upgrades when more expansion slots are unavailable.

4PCIE-PCIE-ENCLOSURE

Brand	‎StarTech
Series	‎4PCIE-PCIE-ENCLOSURE
Item model number	‎4PCIE-PCIE-ENCLOSURE
Operating System	‎Linux
Product Dimensions	‎13.72 x 41.15 x 14.22 cm; 2.3 kg
Item dimensions L x W x H	‎13.7 x 41.1 x 14.2 Centimetres
Colour	‎Black
ASIN	B0BJL7HKD8
Customer Reviews	3.93.9 out of 5 stars 19 ratings3.9 out of 5 stars
Best Sellers Rank	#188,705 in Electronics (See Top 100 in Electronics) #484 in Computer Networking Transceivers #22,974 in Computer Components
Date First Available	Oct. 18 2022
Manufacturer	StarTech.com
Brand	StarTech
Hardware interface	Ethernet
Style	Modern
Item weight	5.07 Pounds
Compatible devices	Desktops, Servers
UPC	065030894630
Global Trade Identification Number	00065030894630
